24GHz radar sensor module with 1 transmitter and 2 receiver antennas, lower power consumption and compact size.

Applications: IP Camera/Doorbell/TV/Smart Lighting/Smart Bathroom

• 24 GHz FMCW Radar

• Range: up to 10 meters

• Distance/Angel/Velocity/Motion Detection

• Dimension: 22 x 18 x 5.8 mm

60GHz radar sensor module with 1 transmitter and 4 receiver antennas, lower power consumption and compact size.

Applications: Baby Monitor/Children Presence Detection (In Cabin)/Driver Monitor System (In Cabin)/Falling Detection

• 60 GHz FMCW Radar

• Range: up to 6 meters

• Range resolution lower to 10cm

• Distance/Angel/Velocity/Motion Detection

• Dimension: 22 x 18 x 5.8 mm

60GHz radar sensor module with 2 transmitter and 4 receiver antennas, lower power consumption and compact size.

Applications: Health Care Monitor/Gesture Recognition (In Cabin)

• 60 GHz FMCW Radar

• Range: up to 2 meters

• Range resolution lower to 10cm

• Distance/Angel/Velocity/Motion Detection

• Dimension: 22 x 18 x 5.8 mm

60GHz radar sensor module with 2 transmitter and 3 receiver antennas, lower power consumption and compact size.

Applications: Long Range IP Camera/Dash Camera Sentry Mode/ Bike Radar/School Bus Monitor/Home Appliance People Detection

• 60 GHz FMCW Radar

• Range: up to 40 meters

• Range resolution lower to 10cm

• Distance/Angel/Velocity/Motion Detection

• Dimension: 35 x 35 x 5.8 mm
